| Εγγύηση | 3 Έτη |
| Κατασκευαστής CPU | AMD |
| Socket | AM4 |
| Chipset | AMD B550 |
| Μέγεθος Μητρικής | Micro ATX |
| Τύπος Μνήμης | DDR4 |
| Dimm Slots | 4 |
| Ταχύτητες Μνήμης | Max. 128GB DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC) 4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200 3000/2933/2800/2666/2400/2133, Un-buffered Memory* Dual Channel Memory Architecture |
| PCI Express 3.0 x1 | 1 |
| PCI Express 3.0 x16 | 1 |
| PCI Express 4.0 x16 | 1 |
| Πλήθος SATA III 6Gb/s | 4 |
| Εσωτερικές Συνδέσεις | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s port |
| Έξοδοι USB 2.0 | 4 |
| Έξοδοι USB 3.2 | 7 |
| Τύπος Raid | 0, 1, 10 |
| Έξοδοι Γραφικών | 1 x DisplayPort** 1 x HDMI®port*** * Graphics specifications may vary between CPU types. ** Supports max. 4K@60Hz as specified in DisplayPort 1.2. *** Supports 4K@60Hz as specified in HDMI 2.1. |
| Wireless | 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Bluetooth v5.2 |
| Ethernet (LAN) | TUF LANGuard |
| Κάρτα Ήχου | Realtek 7.1 Surround Sound High Definition Audio CODEC Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Supports up to 24-Bit/192 kHz playback Audio Features Audio Shielding Rear optical S/PDIF out port Premium audio capacitor |
| Πρόσθετα Χαρακτηριστικά | Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antennas 1 x I/O Shield 1 x M.2 Rubber package 1 x M.2 SSD screw package 1 x TUF Gaming sticker Installation Media 1 x Support DVD Documentation 1 x TUF Certification card |
| Διαστάσεις L x W x H | 244 x 244 mm |
