Electrical Characteristics (Input Rectifier)
- Rated power: 100W
- Mains Input (Three Phase): Input Topology: Three Phase, Neutral + Ground | Input Wiring: L1/L2/L3/N/PE | Nominal Voltage: 360/380/ 400/415V(L-L) | Voltage Range: 110V-300V (L-N) | Nominal Frequency: 50Hz/60Hz | Frequency Range (46~54): Hz / (56~64) Hz
- Mains Input (Two Phase): Input Topology: 2 Phases + Neutral + Ground | Input Wiring: L1/L2/N/PE | Nominal Voltage: 173/190/ 208/220V(L-L), 100/110/ 120/127V(L-N) (Two phases input Configured by user, default is L1, L2 split with 208Vac(L-L)/120Vac(L-N) and 120° phase angle) | Voltage Range: 60V-150V (L-N) | Nominal Frequency: 50Hz/60Hz
Electrical Characteristics (Intermediate DC Circuit)
- Rated power: 100W
- Battery (Three Phase): Nominal Voltage: +/- 192~240V, (16~20)x12V/2x pc | Voltage Range: +/- 160V~ 290V
- Battery (Two Phase): Nominal Voltage: +/- 96~120V (8~10)x12V/2x pc | Voltage Range: +/- 80V~ 180V
Προδιαγραφές προϊόντων
| Εγγύηση | 2 Έτη |
| Είδος | Controller Modules |
| Πρόσθετα Χαρακτηριστικά | Operating Temperature: Range 0°C ~ 40°C / Nominal power & continuous operating mode || Storage Temperature: -15°C~60°C UPS, 0~35°C Battery || Relative Humidity: 0-95% No condensing || Altitude: <1000m for Nominal power || Acoustic Noise: TBD |
| Περιεχόμενα Συσκευασίας | Controller module, Καλώδιο USB, Καλώδιο RJ45, Καλώδιο RS232, Καλώδιο σύνδεσης controller με UPS, Παρελκόμενα εγκατάστασης |
| Βάρος | 3.67 kg | 4.2kg (include guide) |
| Διαστάσεις L x W x H | 275 x 42 x 435 mm | 280 x 42 x 435 mm (include guide) |
