Εγγύηση | 3 Έτη |
Κατασκευαστής CPU | AMD |
Socket | AM5 |
Chipset | AMD B650 |
Μέγεθος Μητρικής | ATX |
Τύπος Μνήμης | DDR5 |
Dimm Slots | 4 |
Ταχύτητες Μνήμης | Up to 128GB, DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC) 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz |
PCI Express 4.0 x16 | 2 |
Πλήθος SATA III 6Gb/s | 6 |
Εσωτερικές Συνδέσεις | 1 x Power Connector(ATX_PWR), 2 x Power Connector(CPU_PWR), 1 x CPU Fan, 1 x Pump Fan, 6 x System Fan, 2 x Front Panel (JFP), 1 x Chassis Intrusion (JCI), 1 x Front Audio (JAUD), 1 x Tuning Controller connector(JDASH), 2 x Addressable V2 RGB LED connector (JARGB_V2), 2 x RGB LED connector(JRGB), 1 x TPM pin header(Support TPM 2.0), 4 x USB 2.0 ports, 2 x USB 3.2 Gen1 Type A ports, 1 x USB 3.2 Gen2 Type C ports, 4 x EZ Debug LED |
Έξοδοι USB 2.0 | 6 |
Έξοδοι USB 3.2 | 11 |
Έξοδοι Γραφικών | 1 x HDMI v2.1 with HDR maximum resolution of 4K @60Hz, 1 x DisplayPort v1.4 maximum resolution of 8K @60Hz, Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
Wireless | AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands, Supports 802.11 a/ b/ g/ n/ ac/ ax, Supports Bluetooth v5.3, Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. Bluetooth v5.3 will be ready in Windows 10 build 21H1 and Windows 11. |
Ethernet (LAN) | Realtek® RTL8125B 2.5Gbps LAN |
Κάρτα Ήχου | Realtek® ALC4080 Codec 7.1-Channel High Performance Audio, Supports S/PDIF output, Supports up to 32-Bit/384 kHz playback on front panel |
Βάρος | Μεικτό: 2.2Kg, Καθαρό: 1.7Kg |
Διαστάσεις L x W x H | Προϊόν: 305 x 244 mm |
