Εγγύηση | 2 Έτη |
Κατασκευαστής CPU | Intel |
Socket | Intel SoC |
Μέγεθος Μητρικής | Micro ATX |
Τύπος Μνήμης | DDR3 |
Dimm Slots | 2 |
Ταχύτητες Μνήμης | Dual Channel DDR3/DDR3L Memory Technology, 2 x DDR3/DDR3L DIMM Slots*, Supports DDR3/DDR3L 1866/1600/1333 non-ECC, un-buffered memory, Max. capacity of system memory: 16GB**, *2GB DRAM per module is not supported., **Due to the operating system limitation, the actual memory size may be less than 4GB, for the reservation for system usage under Windows® 32-bit OS. For Windows®, 64-bit OS with 64-bit CPU, there is no such limitation., Intel® Extreme Memory Profile (XMP) is not supported |
Πλήθος SATA III 6Gb/s | 2 |
Εσωτερικές Συνδέσεις | 1 x Print Port Header, 2 x COM Port Headers, 1 x TPM Header, 1 x Chassis Intrusion and Speaker Header, 1 x CPU Fan Connector (3-pin), 1 x Chassis Fan Connector (3-pin), 1 x 24-pin ATX Power Connector, 1 x Front Panel Audio Connector, 1 x BIOS_PH Connector, 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
Έξοδοι USB 2.0 | 2 |
Έξοδοι USB 3.2 | 2 |
Έξοδοι Γραφικών | 1 x HDMI 3840x2160 @30Hz or 2560x1600 @60Hz, 1 x DVI-D 1920x1200 @60Hz, 1 x VGA 2048x1536 @60Hz |
Ethernet (LAN) | 1 x GBe Realtek RTL8111E |
Κάρτα Ήχου | 7.1 HD Audio (Realtek ALC887 Audio Codec), Surge Protection (ASRock Full Spike Protection), ELNA Audio Caps |
Βάρος | Μεικτό: 0.3Kg |
Διαστάσεις L x W x H | Προϊόν: 226 x 178 mm |
